wire cut

wire cutDKF630 Main indexes of CNC system Model Function&Parameter GK-5Host computer Industrial PC Programmable storage capacity 80G hard disk Display monitor 17 inch LCD Input device USB, keyboard, cable Working code 3B,4B,ISO Memory 32-128M Language Chinese&English Orbiting style Square/circle Unit Metirc/inch HF working voltage of machine tool 60-120V Controlling shaft style 4 shafts synchronously move Min. control unit 1um Max. control unit 10m Output code 3B,ISO Control code ISO Working current of machine tool 4-6A Width of each pulse 4-120us Shape of working voltage wave form for machine tool Grouping rectangle External Dimension 600×500×1800 Packing Dimension Packing Dimension Main index of Machine tool Accuracy of the Machining Max. cutting thicknessCutting angle≥0.01mm400mmZ:12°/50mmCutting speedRoughnessLine speed of the turningwire bobbin>100(m/min)Ra≤1.0um(40m/min)0.8 12 m/sReverse gapAdvancingdistanceofeach pulseAccuracy of the repeatitive position≤0.005 mm≤0.001 mm±0.001 mm The main specification of machine tool Model & Parameter DKM630FZWorktable travel630×800 mm×mmTable loading1200 kgWork table(X×Y)1220×795 mm×mmZ-axis travel400 mmMax. work-piece size(W×D×H)1210×7850×400 mm×mm×mmDiameter of the molybdnum wireΦ0.18 0.20 mmThe machine tool power2.0kwNet weight3000 kgsThe power supply380V/50HZ OR 220V/50HzThe capacity of work solution54.375 LWater tank shape(W×D×H)750×290×300 mm×mm×mmExternal Dimension(W×D×H)1930×1700×2080mm×mm×mmPacking Dimension(W×D×H)2000×2000×2200 mm×mm×mm
